360 Machine Shop helps customers review part designs before and during the machining process. Whether you have a rough concept, an existing print, a STEP file, or a part that needs improved, we can help identify practical ways to make the part easier to machine, use, inspect, or produce.

When Design Support Makes Sense

Design support is useful when a part needs reviewed before machining or improved after testing.
- You have an idea but not a finished print
- You have a model that needs checked for manufacturability
- A prototype needs revised after testing
- A part is too expensive or difficult to machine as designed
- Tolerances, materials, or features need reviewed
- An existing part needs modified to work better
- A design needs turned into something that can be quoted or machined

What We Can Help With

Design and engineering support may include:
- Reviewing prints, sketches, and STEP files
- Basic CAD modeling or model cleanup
- Machinability review
- Material selection discussion
- Tolerance review
- Feature simplification
- Thread, hole, bore, and fit review
- Prototype revision support
- Part modification planning
- Fixture or tooling concept support
- Reverse-engineering discussion from a sample part

Practical Manufacturing Feedback

A design that works on screen may still be difficult, slow, or expensive to machine. We can help review features that affect setup time, tooling access, material choice, strength, tolerance control, and cost.

This may include reviewing:
- Sharp internal corners
- Thin walls
- Deep pockets
- Long reach features
- Small holes or deep holes
- Tight tolerances
- Surface finish requirements
- Unnecessary complexity
- Material availability
- Setup orientation and part holding

From Concept to Machined Part

Not every project starts with complete engineering documentation. We can often help move a project forward using the information you already have.

Useful starting information includes:
- STEP file or solid model
- PDF drawing or 2D print
- Sketch or rough concept
- Photos of an existing part
- Sample part
- Known dimensions
- Description of how the part is used
- Required material or environment
- Quantity needed

Support Through Revisions

Many parts improve after the first prototype or production run. We can help review what worked, what changed, and what needs adjusted before making the next version.

Revision support may include:
- Updating features for better fit or function
- Adjusting tolerances
- Changing material
- Improving machinability
- Reducing unnecessary machining time
- Modifying hole patterns, slots, pockets, or mounting features
- Preparing the part for a small production run

What to Send for a Quote or Review

Helpful information includes:
- Current print, model, sketch, or sample
- Description of the problem or goal
- Quantity needed
- Material preference, if known
- Critical dimensions or fits
- How the part will be used
- What the part connects to or mates with
- Any known issues with the current design
- Desired delivery date

Don’t have a finished design? Send what you have. A sketch, photo, rough dimensions, or sample part may be enough to start the conversation.
